FTTH Cable Production: Step-by-Step Manufacturing Process

Did you know: in excess of 70% of new broadband deployments in the U.S. now use fiber networks that need high-precision manufacturing to meet performance goals.

Shanghai Weiye OFC Equipment runs full-cycle compact fiber unit manufacturing, from sourcing brand fibers like Fujikura or Corning SMF-28e to final test reports that deliver 100% QA.

Our drop cable designs are built for overhead, underground, and direct burial installation, with LSZH, polyvinyl chloride (PVC), and polyethylene (PE) jacket options and configurations from 1–4 cores. We offer single-mode OS1/OS2 and multimode OM2–OM4 grades plus ITU-T G.652D and ITU-T G.657 variants, Pantone sheath colors, and logo printing.

Automation and high-precision equipment keep line speed steady and repeatability high. Typical lead times are 4–5 days for orders under 100 km and seven to ten days for < 500 km, with an MOQ of 1 km and free-replacement warranty for quality problems.

Continue to understand how our materials, tests, and support work together to reduce lifecycle cost and pair the right product with your network.

• Shanghai Weiye OFC Equipment delivers complete production and laboratory testing for U.S. deployments.
• Multiple jacket choices and fiber grades support indoor/outdoor environments.
• Automated production lines provide consistent quality and reliable optical performance.
• Fast lead times, low MOQ, and recognized brand fibers keep procurement predictable.
• Complete reports and after-sales warranty support product reliability and compliance documentation needs.

FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment

When project timelines and performance matter, Shanghai Weiye OFC Equipment provides tailored drop solutions with full test documentation.

As a specialized maker and supplier, Shanghai Weiye OFC Equipment pairs specialized equipment with tight material control. We provide custom builds and services for residential/MDU deployments. Every order comes with 100% quality assurance and complete test reports.

Our lab performs high heat, salt spray, and vibration tests to validate durability. Jacket options cover LSZH, PVC, and PE. Designs cover flat bow-type and self-supporting styles and support brand fibers such as Fujikura and Corning SMF-28e.

• Documented line control and in-process checks for auditable shipments.
• Engineering support for requirements, pilots, and scaling.
• Modern fixturing and calibration reduce variability so every cable matches operator specs.

How We Produce FTTH Cable

At Shanghai Weiye OFC Equipment, manufacturing steps are aligned to network specifications, pairing brand fiber choices with rigorous test routines.

Fiber Selection & Brand Options

We match fiber draw tower to bend radius, loss, and install environment. Options include OS1/OS2 and OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura® and Corning® SMF-28e are offered to satisfy sourcing standards.

Integrating Strength Members

Strength members use dielectric FRP or metallic steel wire. FRP is preferred where non-conductive runs are required. Steel wire provides tensile strength for longer aerial spans and bonding/grounding needs.

Jacket Options and Control

Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for UV/moisture resistance outdoors. Closed-loop control of extruder temperature and capstan speed stabilizes line speed and dimensional tolerances.

In-Process and Final Testing

Inline geometry/concentricity checks run during manufacturing. Final optical tests confirm loss and return loss. Each order includes a 100% test report and lab results from high-temperature, salt-spray, and vibration tests to confirm handling for drop terminations and field use.

Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Lot records and first-article approvals provide traceability and compliance for U.S. projects.

FTTH drop cable types and structures we manufacture

Shanghai Weiye OFC Equipment offers a compact portfolio of drop designs that cover tight indoor routes and exposed aerial spans. Each option pairs tested materials with geometry tuned for field termination and stable optical performance.

The flat bow-type drop keeps a small footprint for risers/ducts. It keeps bend loss low for easy routing in MDU corridors and hallways.

Self-supporting designs for aerial spans

Self-supporting FTTH drop designs use a messenger element to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding and extra tensile strength are required.

Layouts & Strength Members

We provide both dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and unitube flat types balance crush resistance and compact fiber unit for fast terminations.

Indoor/outdoor jackets

Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor durability. Each family is validated for mechanical/optical performance before shipment.

Production line equipment that ensures quality and speed

Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and increase throughput for drop patch preparation.

Our production line uses automated machines that cut and strip drop patch cords to raise throughput and cut labor variability.

The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is ~1.5 s, giving ~20 terminals per minute in production.

Auto Cut & Strip Capabilities

The equipment strips LSZH/PVC jackets and trims FRP or steel strength members to precise stub lengths. Pneumatic cylinder actuators deliver fast, repeatable motion and low downtime.

PLC/photoelectric control for precision and repeatability

PLC logic + photoelectric sensors deliver precise positioning and feedback control. Inline checks update SPC charts so operators can adjust drifts before defects grow.

• Auto scrap ejection and ergonomic loading keep the line clean.
• PCPs document calibration and key parameters.
• Integrated assets and trained operators help meet FTTH volume goals without sacrificing accuracy.

What the CLX-BPO2 Adds

The CLX-BPO2 brings industrial-grade stripping and trimming to our line, reducing cycle time while keeping prep consistent.

Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to increase throughput and standardize terminal quality. The unit runs at an approximate cycle time of 1.5 seconds, producing around 20 preps per minute in production.

PLC/photoelectric control deliver exact detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.

Throughput & Cycle Time

Typical operation speed is ~1.5 seconds per cycle. This converts to steady throughput under continuous line conditions.

Supported Strip and Stub Lengths

The CLX-BPO2 strips LSZH and PVC jackets with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to fit common termination hardware.

Cutting FRP/Steel Members

The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Customized cutters are available for nonstandard sizes to maintain precision.

• Auto-eject scrap and sensor-triggered start reduce idle time.
• Compact size (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg weight ease integration into workcells.
• Cylinder-driven motion and PLC/photoelectric control improve line reliability and reduce maintenance downtime.

Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without compromising quality.

Customized specifications to fit your FTTH system

Shanghai Weiye OFC Equipment configures every order to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.

Choose 1 to 4 cores with SM or MM fiber. Options include OS1/OS2 plus OM2–OM4 along with G.652D and G.657 variants to match your optics and connector plans.

We match sheath colors to Pantone codes for fast field ID and consistent asset tagging.

Jacket materials, print legends, and branding

Select LSZH/PVC/PE jackets based on route and safety rules. Custom legends/logos support inventory and warranty tracking.

Length options, packaging, and special structures

Standard reel lengths are 1/2/4 km with tailored reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.

As a supplier, Shanghai Weiye schedules runs to your plan and provides docs that detail final specs for easy on-site QA.

QA, Testing & Documentation

Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.

Lab Testing: Heat, Salt Spray & Vibration

Our lab conducts high-temperature exposure, salt fog corrosion, and mechanical vibration to qualify materials/assemblies. These tests recreate field stresses for indoor/outdoor applications.

Per-Reel 100% Reports

Every fiber optic cable includes a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.

Traceability & Compliance

Batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.

• In-line checks plus final inspection reduce field failures and lower warranty events.
• Quality packages include specifications confirmation and formatted data for rapid review.
• Ongoing trend analysis drive preventive maintenance and raise long-term reliability.

FTTH Drop Cable Pricing & Cost Drivers

Budgeting for a drop run starts with fiber and jacket choices and is shaped by volume and customization.

Typical prices vary widely—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), reel length, and structural design.

Materials, Grade, Jacket & Structure

The primary cost drivers are fiber grade, jacket material, and the structural type chosen for deployment.

Self-supporting designs and steel strength elements raise material and labor input. Custom colors, logos, and print legends add setup time and impact pricing on small runs.

Length/Volume/Customization Impact

Longer reels and higher volume orders lower unit cost. Short runs often include setup charges and higher unit prices.

• Line changeovers and custom tooling increase lead time and add cost.
• Clear RFQs and line scheduling let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
• Framework agreements and indexed pricing stabilize budgets across phases.

U.S. Lead Times, MOQ & Delivery

Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align crews and sites. Predictable windows cut downtime and control costs when a rollout is underway.

Typical production windows and capacity planning

Typical production windows are 4–5 days for < 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to keep deliveries on time.

The service team provides updates/tracking so installation teams know when reels arrive. For tight schedules, we reserve contingency capacity to accelerate critical-path orders.

Minimum order quantity and why it matters

The MOQ is 1 km. This reflects setup needs such as wire/die adjustments that consume start-up material and scrap.

We review your length and staging plans to choose reel sizes that cut waste and handling. Staggered batches can balance inventory holding with frequent, smaller deliveries to job sites.

Where and How to Deploy

On-site conditions dictate whether a self-supporting aerial, ducted pull, or direct-buried run is the right choice for a project.

Aerial vs Duct vs Direct-Buried

For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to control sag and tension for long-term stability.

Duct installations perform best with low-friction sheaths and crush-resistant builds so pulling avoids fiber damage. PE jackets are common for underground and buried paths where moisture resistance is needed.

Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the fiber core long-term.

Indoor Riser/Plenum & ONT

Indoor riser and plenum routes prefer LSZH to meet flame and smoke rules. Flat drop cable forms strip clean and present controlled stubs for fast ONT terminations.

We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning exposure, and hardware compatibility. Standardized prep from the production line shortens install time and minimizes scrap.

Our approach ensures a consistent install experience across indoor outdoor transitions. That reduces callbacks, faster activations, and reliable field performance for your system.

End-to-end support and after-sales service

Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.

Shanghai Weiye OFC Equipment provides engineering support from early requirements through approved drawings and pre-production builds. We deliver documentation templates and clear installation notes so field crews share a unified plan.

After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full reports and traceability to help QA acceptance.

• 24/7 availability for status updates and technical guidance.
• Warranty with free replacement if any quality problems are confirmed.
• Schedule coordination for expedites and urgent changes.
• Configuration control so shipped items match agreed requirements every time.

Final Thoughts

Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.

We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented trials to support U.S. field acceptance.

A hardened production line, including CLX-BPO2-enabled prep machines, reduces variability and speeds turnaround. Our equipment and machines standardize strip and stub lengths so installers get consistent results at turn-up.

From fiber selection through jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment stays on plan.

Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every shipment with laboratory validation and responsive support.
